About this part
Monster Blower clip-on heat sink and fan from Hot Racing, for the 3 cell setup. A 50x50x11mm 7-blade fan pushes air across the motor heat sink for better cooling. Built for the 1/8 Arrma Kraton, Notorious, Outcast, Senton, Talion and Typhon BLX, or your own custom project. Black and blue anodized aluminum.
Features
- Forced airflow over motor heat sink for better cooling, efficiency and performance
- Large 50x50x11mm 7-blade fan
- Clip-on design for simple installation
- Black and blue anodized aluminum heat sink
- EC5 adapter
- 12AWG and 24AWG silicone wire
You will receive
- One (1) clip-on heat sink with fan
- One (1) EC5-style adapter connector
Requirements
- Loosen fan screws during installation, then retighten to minimize tweaking and binding
- Medium strength thread lock (blue) on fan mount screws
- Protect the fan blades
- Uses an EC-5 connector. For another connector type, switch connectors or use an adapter.
Specifications
- Fan size: 50x50x11mm
- Input voltage: 11.1V (12V max)
- Fits motors with a can diameter of 1.6 inches (40mm)
Comments
- Running a single 6 cell pack? Order AON505F02 instead.
- FITS:
- Arrma 1:10 4x4 Senton 6S BLX
- Arrma 1:7 4x4 Mojave 6S BLX V5
- Arrma 1:7 Felony
- Arrma 1:7 Fire
