Air Shocks, Aluminum Black Internal Spring, 125mm - Hot Racing

About this part

125mm internal spring air shocks, aluminum and black anodized. Built for Axial or any custom rock crawler project that needs shocks that work. Two rates are included so you can dial in the ride. Air damping keeps it controlled.

Features

• CNC machined aluminum bodies, black anodized
• CNC machined aluminum lower cap with shaft guide, silver anodized
• Precision machined 6mm stainless shaft
• Delrin lower shaft seal
• Air damping
• Internal springs in two rates: Black (stiff) and Silver (medium)
• All aluminum is anodized for corrosion resistance and looks
• YOU RECEIVE:
• Two assembled shocks
• Two black (stiff) springs
• Two silver (medium) springs
• Four 4.8mm ball mounts
• Four 3 x 12mm cap head screws
• Eight 6mm OD o-rings
• Two M3 lock nuts
• REQUIRES: Installation on vehicle. Recommended with SPL10G08 for smoother action.

Specifications

• Extended center-to-center: 125mm (4.92 in)
• Compressed center-to-center: 85mm (3.35 in)
• Overall length: 133mm (5.2 in)
• Body diameter: 11mm (0.43 in)
• Shaft diameter: 6mm (0.24 in)
• FITS: Axial AX-10 Deadbolt, AX-10 Ridgecrest Crawler, RR-10 Bomber, SCX-10 II, SCX-10 II 6 wheel, SCX-10 II Deadbolt.
