Mini Servo, Raw 100, Programmable - Reefs RC

About this part

REEFS Raw 100 mini programmable servo. A high torque, high speed mini coreless servo with a submarine waterproof build, a magnetic angle sensor and an all metal gear set. Fully programmable with the REEFS LINK, which is sold separately. BEC is not required, but Reefs recommends it for max performance.

Features

• Submarine waterproof. Magnetic angle sensor. Pulse width modulation control. REEFS LINK required for programming (optional). All metal gears. CNC aluminum casing with heat sink.

Specifications

• Voltage: 6v-8.4v. Bearing: 2BB. Temp rate: -15C to +70C. Weight: 1.05oz / 30g. Dimensions (LWH): 1.16 x .55 x 1.14 in / 29.5 x 14 x 29 mm. Torque: 85oz @ 6.0V, 95oz @ 7.4V, 103oz @ 8.4V. Speed: .11 sec @ 6.0V, .10 sec @ 7.4V, .08 sec @ 8.4V. Spline: 25T standard. Dead band width: 2s. Unload current: 180mA, 200mA, 230mA, 260mA @ 4.8V, 6.0V, 7.4V, 8.4V. Load current: 1200mA, 1400mA, 1500mA, 1800mA @ 4.8V, 6.0V, 7.4V, 8.4V.
